Analysis of the Structure Simulation of USU Car Chassis Structures with Static Loads Using Ansys Software 14.5

Introduction

The design of a car chassis is a crucial aspect in ensuring vehicle safety and performance. A well-designed chassis can withstand various loads and stresses, providing a comfortable and secure driving experience. In this study, we aim to analyze the effects of static load simulation on the USU I and USU II engine chassis using Ansys 14.5 software. The simulation results will provide valuable insights into the behavior of the chassis under static loads, enabling engineers to optimize the design and improve the overall performance of the vehicle.

Background

The USU engine chassis is a critical component of the vehicle, responsible for supporting the engine, transmission, and other components. The chassis design must ensure that it can withstand various loads, including static loads, dynamic loads, and fatigue loads. Static loads refer to the loads that occur when the vehicle is stationary, such as the weight of the vehicle, passengers, and cargo. Dynamic loads, on the other hand, refer to the loads that occur when the vehicle is in motion, such as the forces exerted by the road and the wind. Fatigue loads refer to the loads that occur over a prolonged period, such as the repeated stress and strain on the chassis due to driving conditions.

Methodology

This study was conducted in several stages, including:

Chassis Modeling: The USU I and USU II engine chassis were modeled using Solidworks Premium 2011 software. The models were created with precise dimensions and geometry to accurately represent the actual chassis.
Simulation Elements: The simulation elements were created using Ansys 14.5 software. The elements were defined to simulate the static loads on the chassis, including the weight of the vehicle, passengers, and cargo.
Simulation Analysis: The simulation analysis was performed using Ansys 14.5 software. The analysis involved simulating the static loads on the chassis and analyzing the resulting deflections, stresses, and strains.

Results

The simulation results for the USU I engine chassis with a load of 700 N are as follows:

Maximum deflection: 0.96 mm
Ground clearance deflection: 0.6415 mm
Maximum stress: 22,563 MPa
Maximum strain: 11.65e-5 mm/mm

The simulation results for the USU II engine chassis with a load of 700 N are as follows:

Maximum deflection: 3.29 mm
Ground clearance deflection: 2.236 mm
Maximum stress: 53.217 MPa
Maximum strain: 26.71e-5 mm/mm

When the load is raised to 25 kN in the USU I engine chassis, the simulation results are as follows:

Maximum deflection: 31.542 mm
Ground clearance deflection: 21.682 mm
Maximum stress: 741.59 MPa
Maximum strain: 371.12e-5 mm/mm

When the load is raised to 3.8 kN in the USU II engine chassis, the simulation results are as follows:

Maximum deflection: 17.074 mm
Ground clearance deflection: 11.582 mm
Maximum stress: 277.64 MPa
Maximum strain: 139.39e-5 mm/mm

Discussion

The simulation results show that the USU II engine chassis has a larger deflection and stress compared to the USU I engine chassis. This is likely due to differences in the design and material used in both chassis. The simulation results also show that the loading effect on the chassis can be determined through simulation with Ansys software, provided the chassis geometry modeling is done correctly.

Conclusion

This study shows that the simulation of elements using Ansys 14.5 software is an effective tool for analyzing the strength of USU engine chassis. The simulation results can be used to optimize chassis design to be able to withstand the loads that occur during vehicle operation.

Suggestion

This research can be expanded by simulating dynamic load simulations and fatigue analysis to study the behavior of USU engine car chassis under realistic driving conditions. This will provide valuable insights into the behavior of the chassis under various loads and stresses, enabling engineers to optimize the design and improve the overall performance of the vehicle.

The Importance of Simulation Elements

Simulation of elements is a valuable tool in vehicle design and development. By using a simulation, engineers can evaluate the strength and stability of the vehicle structure before carrying out the physical prototype. This makes it possible to identify and overcome potential design problems early on, reducing the cost and development time.

Deeper Analysis

This simulation provides a deep understanding of the behavior of USU engine car chassis under the static load. The simulation results show that the USU II engine chassis has a larger deflection and stress compared to the USU I engine chassis. This is likely due to differences in the design and material used in both chassis.

Limitations of the Study

This study has several limitations. The simulation was performed using Ansys 14.5 software, which may not accurately represent the actual behavior of the chassis under various loads and stresses. Additionally, the study only analyzed the static loads on the chassis, and did not consider the dynamic loads and fatigue loads.

Future Research Directions

Conclusion

In conclusion, this study shows that the simulation of elements using Ansys 14.5 software is an effective tool for analyzing the strength of USU engine chassis. The simulation results can be used to optimize chassis design to be able to withstand the loads that occur during vehicle operation.
