Design of Microstrip Antenna Patch Quadrilateral Array 8x1

Oct 13, 2025 by miodeya.com 9 views

Introduction

In the world of modern communication, the radio frequency spectrum is one of the very valuable and limited resources. Every country around the world seeks to optimize the use of this frequency to meet the increasing communication needs along with technological advances. However, the availability of the spectrum is not comparable to the growing demand. One innovative solution proposed by researchers is the utilization of high frequency spectrum, especially at a frequency of 60 GHz which has not been fully explored. This article will discuss the design of a microstrip antenna using an 8 element array for the application in the 60 GHz band.

Background and Motivation

The increasing demand for high-speed data communication and wireless networks has led to the exploration of new frequency bands for communication. The 60 GHz frequency band is one of the most promising options due to its wide bandwidth and high frequency. However, the design of antennas for this frequency band is a challenging task due to the small wavelength and high losses. Microstrip antennas are a popular choice for high-frequency applications due to their simplicity, low cost, and high gain. However, the design of microstrip antennas for the 60 GHz frequency band requires careful consideration of the antenna parameters to achieve optimal performance.

Design of Microstrip Antenna Patch Quadrilateral Array 8x1

The design of the microstrip antenna patch quadrilateral array 8x1 is intended to improve performance in communication at high frequency. The array antenna consisting of 8 elements is designed to produce optimal antenna parameters. The advantage of the use of array antennas is that an increase in gains, which is very important in the application of 60 GHz communication that requires high efficiency in signal transmission.

Design Parameters

The design parameters of the microstrip antenna patch quadrilateral array 8x1 are as follows:

Frequency: 60 GHz
Array configuration: 8x1
Antenna size: 10 mm x 10 mm
Substrate material: Rogers RT/Duroid 5880
Dielectric constant: 2.2
Thickness: 1.5 mm

Simulation and Analysis

The design of the microstrip antenna patch quadrilateral array 8x1 was simulated using the finite element method (FEM) and the results were analyzed to determine the antenna parameters. The simulation results show that the antenna has a return loss of -14.67 dB, which indicates that this antenna is able to reflect very small signals, so that the transmission efficiency becomes higher. In addition, the Voltage Standing Wave Ratio (VSWR) of the antenna was recorded at 1.54, showing that the antenna has a good compatibility with the transmission channel. The width of the bandwidth produced is 0.8 GHz, which shows the ability of the antenna to support various applications in adjacent frequencies. Antenna gain produced by 16.8 dB shows the ability of the antenna to increase the signal received or emitted.

Test Results

The test results of the microstrip antenna patch quadrilateral array 8x1 show that the antenna has good performance in terms of return loss, VSWR, and bandwidth. The test results are as follows:

Return loss: -14.67 dB
VSWR: 1.54
Bandwidth: 0.8 GHz
Antenna gain: 16.8 dB

Conclusion

In conclusion, the design of the microstrip antenna patch quadrilateral array 8x1 for the application of the 60 GHz communication system shows that this approach can meet the needs of modern communication. Utilization of high frequency spectrum with efficient antenna design is very important to support the rapid development of communication technology. With test results that show good performance, this antenna has the potential to be implemented in various future communication applications.

Future Work

Future work on this project includes the optimization of the antenna design to improve its performance and the development of a prototype of the antenna for testing and validation.
