Calculating Heat Flow for Each Section

Oct 13, 2025 by miodeya.com 2 views

What is the Heat Flow in Btu/hour through the Following Assembly at a 40-degree Fahrenheit Difference?

Understanding Heat Transfer and U-factor

Heat transfer is a fundamental concept in physics that deals with the movement of thermal energy from one body to another due to a temperature difference. The rate of heat transfer depends on several factors, including the temperature difference, the area of the assembly, and the thermal conductivity of the material. The U-factor, also known as the heat transfer coefficient, is a measure of the rate of heat transfer through a material or assembly. It is defined as the amount of heat that flows through a unit area of the assembly per unit time, per unit temperature difference.

Calculating Heat Flow

To calculate the heat flow through the assembly, we need to use the formula:

Q = U * A * ΔT

Where: Q = heat flow (Btu/hour) U = U-factor (Btu/hour-ft²-°F) A = area of the assembly (ft²) ΔT = temperature difference (°F)

Given Data

We are given the following data:

80 square feet of the assembly have a U-factor of 0.062
20 square feet have a U-factor of 0.90
Temperature difference = 40°F

Calculating Heat Flow for Each Section

Let's calculate the heat flow for each section of the assembly:

Section 1: 80 square feet with U-factor of 0.062

Q1 = 0.062 * 80 * 40 Q1 = 199.2 Btu/hour

Section 2: 20 square feet with U-factor of 0.90

Q2 = 0.90 * 20 * 40 Q2 = 72 Btu/hour

Total Heat Flow

To find the total heat flow through the assembly, we need to add the heat flow for each section:

Q_total = Q1 + Q2 Q_total = 199.2 + 72 Q_total = 271.2 Btu/hour

Answer

Based on the calculations, the total heat flow through the assembly at a 40-degree Fahrenheit difference is 271.2 Btu/hour.

Conclusion

In this article, we discussed the concept of heat transfer and the U-factor, and used the formula Q = U * A * ΔT to calculate the heat flow through a given assembly. We calculated the heat flow for each section of the assembly and found the total heat flow to be 271.2 Btu/hour.
