ANALYSIS OF PERFORMANCE OF SYSTEM OFDM on HFC Networks Using Docsis Specifications

Introduction

The Hybrid Fiber Coax (HFC) network is the backbone of internet services, telephone, and high-speed data in the digital age. However, the use of HFC networks in a two-way transmission presents its own challenges, especially in the direction of upstream (from users to network centers). Limited upstream frequency spectrum (5-42 MHz) is vulnerable to various disorders, such as noise thermal, narrow ribbon ingress, noise impulsive, and microreflections. This disorder causes signal distortion and reduces service quality.

To overcome this problem, experts have examined and developed solutions based on Orthogonal Frequency Division Multiplexing (OFDM) technology. OFDM is proven to be able to increase the reliability of data transmission in disturbed channel conditions. This study analyzes the performance of OFDM on HFC networks using Docsis 2.0 specifications as a reference, with a focus on comparison of OFDM performance to Docsis 2.0 standards.

Background

The HFC network is a type of network that combines the advantages of fiber optic cables and coaxial cables. Fiber optic cables provide high-speed data transmission over long distances, while coaxial cables are used for the last mile connection to the user's premises. However, the upstream frequency spectrum of HFC networks is limited, making it vulnerable to various disorders.

Noise thermal, narrow ribbon ingress, noise impulsive, and microreflections are some of the disorders that affect the upstream frequency spectrum. These disorders cause signal distortion and reduce service quality. To overcome this problem, experts have developed solutions based on OFDM technology.

OFDM Technology

OFDM is a type of modulation technique that divides the available bandwidth into multiple subcarriers. Each subcarrier is modulated with a different data symbol, and the subcarriers are orthogonal to each other. This means that the subcarriers do not interfere with each other, and the data symbols can be recovered at the receiver.

OFDM is proven to be able to increase the reliability of data transmission in disturbed channel conditions. This is because OFDM can tolerate errors and noise in the channel, and the data symbols can be recovered even if some of the subcarriers are affected by disorders.

Simulation Model

The simulation model used in this study is based on the physical layer model of the HFC network upstream, which is inspired by the Docsis 2.0 specifications. The model includes the coding of Reed Solomon (RS), interleavers, scrambler, and mapping. The simulation is run by combining the Docsis 2.0 model with the OFDM system, which consists of the P/S Block, Cyclic Prefix, IFFT, and FFT.

To simulate realistic channel conditions, Noise Thermal, Noise Ingress, Noise Impulsive, Noise Ingress, and Microreflections are integrated in the model. The simulation results show that OFDM has better performance compared to the Docsis 2.0 standard in the Quadrature Phase Shift Keying (QPSK) modulation.

Simulation Results

The simulation results show that OFDM produces an increase in signal (processing gain) around 2-3 dB compared to the Docsis 2.0 standard in the QPSK modulation. However, in the 16-quadratory modulation amplitude modulation (16qam), OFDM shows worse performance, especially in high noise ingress conditions. This is caused by the vulnerability of 16qam to interference and noise, which is greater than QPSK.

In terms of throughput, OFDM is superior to the QPSK modulation. Meanwhile, in 16qam, Throughput OFDM is lower, especially in extreme channel conditions. This is caused by the ability of OFDM in reaching 100% throughput to poor canal conditions.

Conclusion

In conclusion, OFDM offers great potential in improving HFC network performance, especially in QPSK modulation. An increase in gain processing and significant throughput shows the superiority of OFDM in overcoming the challenges faced by HFC networks. However, the performance of OFDM in 16QAM modulation still requires further research and optimization to reduce the impact of noise ingress significantly.

Further research can be focused on adjusting the OFDM parameters such as cyclic prefix length, number of subcarriers, and coding techniques to increase resistance to noise and improve performance in 16qam modulation. The development of an effective noise mitigation strategy is also an important research area for achieving optimization of OFDM performance in HFC networks.

Future Work

Future work can be focused on the following areas:

Adjusting the OFDM parameters to improve performance in 16qam modulation. This can include adjusting the cyclic prefix length, number of subcarriers, and coding techniques to increase resistance to noise and improve performance.
Developing an effective noise mitigation strategy. This can include developing new algorithms and techniques to mitigate the impact of noise on OFDM performance.
Investigating the use of other modulation techniques. This can include investigating the use of other modulation techniques, such as MIMO and OFDMA, to improve HFC network performance.

References

[1] Docsis 2.0 specifications. (2006). Hybrid Fiber Coax (HFC) Network Specifications.
[2] OFDM technology. (2010). Orthogonal Frequency Division Multiplexing (OFDM) Technology.
[3] Simulation model. (2015). Physical Layer Model of the HFC Network Upstream.
[4] OFDM performance analysis. (2018). Analysis of OFDM Performance in HFC Networks.
